CHAPTER 2PRODUCT OVERVIEW
2–12 www.zoll.com 9650-0912-01 Rev. N
The following table summarizes some of the more common softkeys.
Defib Mentor Mode (Optional)
Defib Mentor™ mode is a nonclinical tutorial mode available when the Mode Selector is
turned to MONITOR. When in this mode, the device displays a brief description of each front
panel control’s function when that control is activated.
Note: Do not run the Defib Mentor mode with a patient connected to the R Series unit.
To access Defib Mentor mode:
1. Turn the Mode Selector to MONITOR.
2. Press the Options softkey.
3. Press MORE.
Additional options appear.
4. Press Mentor.
5. Press Confirm Mentor Mode.
The unit is now in Defib Mentor Mode, a non-clinical operating mode.
6. Activate a front panel control (except the Mode Selector or the Exit Mentor softkey).
A brief description of that control’s function appears on the screen.
To exit Mentor mode, press the Exit Mentor softkey or turn the Mode Selector to OFF,
DEFIB, or PACER.
Note: After 60 seconds of non use in the Mentor mode, the R Series returns to MONITOR
mode.
Softkey Action
Next Item
Next Field
Moves the highlighting down to the next item in a vertical list.
Prev Item Moves the highlighting up to the previous item in a vertical list.
Next Digit Moves the highlighting to the right in a series of letters or digits.
Prev Digit Moves the highlighting to the left in a series of letters or digits.
Inc
Inc Digit
Increases the highlighted value or digit.
(For example, changes 2 to 3 or B to C).
Dec
Dec Digit
Decreases the highlighted value or digit.
(For example, changes 2 to 1 or B to A).
Newer Moves the highlighting to the adjacent item with the more recent date or time.
Older Moves the highlighting to the adjacent item with the older date or time.
Enter Accepts the settings with the values currently shown.
Return Displays the previous menu.
Next Param Moves the highlighting to the next parameter.
Prev Param Moves the highlighting to the previous parameter.
Change Value Changes the value of the selected parameter.
