ZOLL R Series Service Manual

R Series Service Manual
9650-0903-01 Rev. L 4-3
9310-0894 Isolator, ECG 15
Back Panel
0140-0202 Ferrite Core Flat Cable Type 100
0162-0033 Washer.Ribbed Lock.M14. 15mm ID.x 22mm OD.x 2mm.ZINC. 25
0163-0029 Washer.Lock Int.7/16.0.456"ID.0.765"OD.0.036"THK.SS 28
0163-0286 Scr. #2-56, MCH, 5/16", PNH, PHL, STL, Int 21
0163-0401 Scr. PPH. #4.x 0.312".STL./ZNC.Hi/Lo 8
0163-2500 Nut.Hex.7/16 - 24 Unf.Chrome Plated Brass Panel Nut 26
0501-0001 Ty-Rap cable tie STD 18 LB .093W X 3.62 L 99
1009-0902-01 Assembly, Communications Module 20
1009-0929-01 Assembly, Cable Organizer 33
1009-0930-01 Assembly, NIBP Fitting-O-ring 30
9150-0503 Connector, MFC, Assembly 31
9161-0032 Gasket, Compact Flash, USDB 23
9310-2786 Connector Panel 29
9330-0717 Mount, Adhesive, Color inverter PCB 22
9500-0764 Assembly, Cable, SYNC, IN/OUT, ECG, RS232 27
9500-0902 Cable, Isolated Power Supply to EtCO2 24
9500-0991 Assembly, SpO
2
, internal connector 32
PCB Brick Assembly
Complete
0140-5622 Mag.Round Cable Core assembly, Ferrite 90
Part Number Description Item number

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
