9650-0912-01 Rev. N ZOLL R Series Operator’s Guide 11–1
Chapter 11
File Transfer
This chapter describes procedures for transferring files from the R Series defibrillator to an
external system, such as a personal computer or handheld device. It also explains how to
remove, install and erase a Compact Flash card.
Transferring Files to an External Device
You can transfer the following files from the R Series defibrillator to an external device:
• Device check, activity log, and full disclosure waveforms
• Defibrillator test information
The unit includes the following data transfer features:
• 802.11 Wi-Fi (optional)
• USB device connector (optional)
• Compact flash card slot
To retrieve and review event files, you need one of the following software packages installed on
the receiving equipment:
• ZOLL CodeNet Central software
• ZOLL RescueNet Code Review software
To retrieve and review maintenance files, you need ZOLL Defib Dashboard software installed
on the receiving equipment.
R Series defibrillators use the Microsoft Windows file structure for stored records. Files can be
transferred to a properly equipped Windows-based personal computer or handheld device. With
CodeNet Central software, the personal computer allows the user to access the files for review.

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
