CHAPTER 12 FILE TRANSFER
12–6 www.zoll.com 9650-0904-01 Rev. N
Note: Enable Report ID must be enabled in System Configuration mode for the report screen
to appear (See the R Series Configuration Guide). If Enable Report ID is set to No,
then the screen will not be displayed and the report will be sent immediately.
7. To send the report, press the Send Report softkey. The R Series is now in Wi-Fi Transfer
Mode and a status text message box appears in the middle of the screen and describes the
status of the file being sent. When the full disclosure file is transferred, the messages
TRANSFER COMPLETE and Full Disclosure Was Sent are displayed.
8. To erase the report, press the Erase Report softkey. To keep the report and return to the
Transfer Mode screen, press the Return softkey.
Note: If you are out of the range of an access point, the data will not be transferred and the
message Wi-Fi Network Not Found is displayed. Press the Return softkey to return to
the previous menu and try again.
To exit Wi-Fi/DataTransfer Mode, press the Return softkey and then the Exit Transfer
softkey or switch the Mode Selector to OFF.
Transferring Device Check and Activity Log Files
Through Wi-Fi (R Series Plus Only)
Before you begin, ensure the Wi-Fi card is properly seated with the name R Series Data
COMM or Data COMM II facing up in the compact flash slot. Make sure that the Wi-Fi guard
has been attached.
To transfer data through Wi-Fi:
1. Turn the Mode Selector to ON.
2. Press the Manual Mode softkey.
TRANSFER COMPLETE
Erase
Report
DATA TRANSFER MODE
Return
Full Disclosure Was Sent
TRANSFER FAILED
DATA TRANSFER MODE
Return
Full Disclosure Not Sent
