EID for Non–Life-Support Functions
Guidance and manufacturer’s declaration – electromagnetic immunity – for non–
life-supporting equipment and systems.
The non–life-support functions
a
of the R Series are intended for use in the electromagnetic environment
specified below. The customer or user of the R Series should ensure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment – guidance
Portable and mobile RF communications
equipment should be used no closer to any
part of the R Series, including cables, than the
recommended separation distance calculated
from the equation applicable to the frequency
of the transmitter.
Recommended separation distance
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
3 Vrms
d = 1.2
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to 2.5 GHz
3 V/m
d = 1.2 80 MHz to 800 MHz
d = 2.3 800 MHz to 2.6 GHz
where
P is the maximum output power rating
of the transmitter in watts according to the
transmitter manufacturer and d is the
recommended separation distance in meters.
Field strengths from fixed RF transmitters, as
determined by electromagnetic site survey,
b
should be less than the compliance level in
each frequency range.
c
Interference may occur in the vicinity of
equipment marked with the following symbol:
NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects, and people.
a. The non–life-support functions on the R Series are defined to be any function not listed as a life-support function in
the "EID for Life-Support Functions" table (Note a). Specifically, this function is SpO
2
.
b. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile
radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be
considered. If the measured field strength in the location in which the R Series is used exceeds the applicable RF
compliance level above, the R Series should be observed to verify normal operation. If abnormal performance is
observed, additional measures may be necessary, such as reorienting or relocating the R Series.
c. Over the frequency ranges 150 kHz to 80 MHz field strength should be less than 3 V/m.
