ZOLL R Series Service Manual

R Series Service Manual
9650-0903-01 Rev. L 1-29
16.0 Advisory Message Test (Manual/Advisory Units)
Tools Needed: Impulse 4000
Test Setup:
1. Connect the OneStep cable via the adapter (D.N.I #3010-0378) to the defibrillator analyzer.
Do this... Observe this... Pass/Fail
16.1 Connect OneStep cable to the simulator.
Turn the selector switch to DEFIB mode (for
AED units turn to ON, and select MANUAL
MODE.)
16.2 Select VF (ventricular fibrillation) on the Impulse
4000, then press the ANALYZE button.
ANALYZING ECG message displays.
STAND CLEAR message displays.*
SHOCK ADVISED message displays.
PRESS SHOCK message displays*+
*Advisory audio prompts are user configurable.
+If configured for auto charge. PRESS CHARGE message displays if not
configured to auto charge.
oo
16.3 Press the SHOCK button. Unit discharges.
oo
16.4 Select the NSR (normal sinus rhythm) on the
simulator, then press the ANALYZE button.
ANALYZING ECG message.
STAND CLEAR message.*
NO SHOCK ADVISED message.*
*Advisory audio prompts are user configurable.
oo
Record your results on the Maintenance Test Checklist.

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
