ZOLL R Series Service Manual

R Series Service Manual
1-4 9650-0903-01 Rev. L
1.0 Physical Inspection of the Unit
Tools Needed: None.
Test Setup: None.
Observe this... Pass/Fail/NA
1.1 Housing
Is the unit clean and undamaged?
ooo
1.2 Does the unit show signs of excessive wear?
ooo
1.3 Is the handle undamaged?
ooo
1.4 Does the recorder door open and close properly?
ooo
1.5 Are input connectors clean and undamaged?
ooo
1.6 Are there any cracks in the housing?
ooo
1.7 Do the front panel or keypad buttons have any damage or cracks?
ooo
1.8 Are there any loose housing parts?
ooo
1.9 Do the paddle latches work properly?
ooo
1.10 Paddles
Do the adult and pedi plates have major scratches or show signs of damage?
ooo
1.11 Do the adult shoes slide on and off easily to expose the covered pedi plates?
ooo
1.12 Are the paddles clean (e.g., free of gel) and undamaged? (if applicable)
ooo
1.13 Cables
Are all cables free of cracks, cuts, exposed or broken wires?
ooo
1.14 Are all bend/strain reliefs undamaged and free of excessive cable wear?
ooo

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
