AED Operation
9650-0904-01 Rev. N ZOLL R Series Operator’s Guide 3–5
• Shock 2 - 150 joules
• Shock 3 - 200 joules
The default energy selections for pediatric patients are:
• Shock 1 - 50 joules
• Shock 2 - 70 joules
• Shock 3 - 85 joules
After the third shock, all subsequent shocks are delivered at the same energy as the third shock
in both Adult and Pediatric modes.
2 Analyze
WARNING! Do not analyze the patient ECG during patient movement. A patient must be motionless
during ECG analysis. Do not touch the patient during analysis. Cease all movement via
stretcher or vehicle before analyzing the ECG.
The R Series automatically begins the analysis of the patient’s ECG rhythm, displays an
ANALYZING ECG message for 5 seconds, then announces and displays a STAND CLEAR
message. If therapy electrodes have not been properly connected to the patient, an ATTACH
PA D S or CHECK PADS message is displayed and analysis will be inhibited.
Note: If the R Series has been configured to perform extra CPR, it displays a CHECK
PULSE voice prompt and the message appears for 10 seconds. Then it displays an IF
NO PULSE, PERFORM CPR message along with a voice prompt for the configured
duration before analysis begins. You can start an ECG analysis during the CPR interval
by pressing the ANALYZE softkey.
An ANALYZING ECG message is displayed while the patient’s ECG is analyzed. Once the
analysis is completed, the unit indicates whether or not a shock is advised.
WARNING! ECG rhythm analysis does not warn of patient asystole, which is not a shockable
rhythm.
ANALYZING ECG
Manual
Mode
ECG
STAND CLEAR
