CHAPTER 13 TROUBLESHOOTING
13–2 www.zoll.com 9650-0912-01 Rev. N
Monitor
3. Pad Expired; Replace Pads Check the expiration date on OneStep electrodes, and
replace them if they are expired.
4. Poor Pad Condition; Replace
Pads
OneStep electrode condition sensor indicates that the
electrode gel has dried or aged beyond its specifications.
The electrodes may no longer provide optimal therapy.
Replace therapy electrodes. (If emergency defibrillation is
required and spare hands-free therapy electrodes or
paddles are not immediately available, it may be advisable
to use the pads in question rather than delay therapy.)
Symptom Recommended Action
1. Unit does not turn on or unexpect-
edly shuts off.
Check that battery pack is properly installed.
Verify the unit is plugged into AC power.
Replace battery pack with a fully charged battery pack.
2. X FAULT XX message
A fault has been detected.
Attempt to clear the X FAULT XX message by turning
the Mode Selector to OFF for more than 10 seconds,
then back to the desired operating mode.
Note: Some settings (e.g. alarm settings, lead selection,
ECG size) may need to be restored.
3. SET CLOCK message
Set time and date information.
Verify that the internal lithium battery has been replaced
within the last 5 years. Contact ZOLL Technical Service
Department for assistance
4. ECG LEAD OFF message
Check that ECG cable or OneStep Pacing cable is
connected to patient and instrument.
Check that ECG electrodes or OneStep Pacing or
Complete electrodes are making good contact and are
not dried out.
If changing from 5-lead ECG patient cable to 3-lead
ECG patient cable, remove the 5 lead cable then turn
unit OFF for at least 10 seconds.
Replace ECG cable or OneStep cable.
5. POOR LEAD CONTACT message
Check that ECG cable or OneStep Pacing cable is
connected to patient and instrument.
Check that ECG electrodes or OneStep Pacing or
Complete electrodes are making good contact and are
not dried out.
If changing from 5-lead ECG patient cable to 3-lead
ECG patient cable, remove the 5 lead cable then turn
unit OFF for at least 10 seconds.
Replace ECG cable or OneStep cable.
