R Series Service Manual

1-24 9650-0903-01 Rev. L

12.0 Synchronized Cardioversion Test

Tools Needed: Impulse 4000 or equivalent defibrillator analyzer.

Test Setup:

1. Connect the OneStep cable via the adapter (D.N.I #3010-0378) to the defibrillator analyzer.

2. Select cardioversion on analyzer. Input 1mV ECG signal at 60 BPM.

Do this... Observe this... Pass/Fail

12.1 Press LEAD button to select PADS and Size

X1.

12.2 Press the SYNC softkey on the defibrillator.

Enter synchronized cardioversion timing test

mode on the defibrillator analyzer.

NOTE: Press the SYNC softkey again if the unit

is configured for Remote Sync.

Sync appears on display.

Sync markers display on the monitor. The sync marker appears as a down

arrow over the ECG R-wave peaks on strip chart and display.

12.3 Select 200J.

12.4 Press the CHARGE button. When the SHOCK

button lights, press and hold the SHOCK

button.

Defibrillator discharges.

Observe that the R-wave to energy delivered (sync delay) is less than 60

milliseconds on the analyzer display.

Record your results on the Maintenance Test Checklist.
