ZOLL R Series Service Manual

R Series Service Manual
4-8 9650-0903-01 Rev. L
9500-0748 Cable, Assembly, Main Switch 58
9500-0772 Cable Assembly, Main Switch, Non-Pacing 73
9305-0928-01 Label, Pacer Overlay, BLS 75
Printer and Battery Well
0163-0416 Scr. #6-32, MCH, 7/16", PNH, PHL, STL, Ext. 36
1009-0903-01 Assembly, Battery Well Module 76
1009-0919-01 Assembly, Printer 77
0163-0102 Scr. #6-32, MCH, 5/16", PNH, PHL, SST, Int. 78
Labels (English)
9305-0789-01 Label, Battery Well, Rear 79
9305-0797-01 Label, Panel Connector Rear, No Options 80
9305-0799-01 Label, Panel Connector Rear, w/SPO2 80
9305-0929-01 Label, Panel Connector Rear, w/SPO2/EtCO2 80
9305-0930-01 Label, Panel Connector Rear, w/NIBP/SPO2/EtCO2 80
9305-0942-01 Label, Panel Connector Rear, w/EtCO2/NIBP 80
9305-000998-01 Label, Panel Connector Rear, w/EtCO2 80
9305-0792-01 Label, Test Port 81
9310-0888 Guard, SpO
2
82
9330-0761 Adhesive Guard, SpO
2
83
9305-0798 Label, logo, Masimo 84
Front Panel Keypads
(English)
Part Number Description Item number

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
