ZOLL R Series Service Manual

9650-0904-01 Rev. N ZOLL R Series Operator’s Guide v
Full Disclosure Recording................................................................................................. 11-8
Incident Logs .................................................................................................................... 11-8
Printing an Incident Log ............................................................................................ 11-8
Erasing Summary Report and Full Disclosure.................................................................. 11-9
Manual Erasure ........................................................................................................11-9
Automatic Erasure ....................................................................................................11-9
Formatting the Disk ................................................................................................... 11-9
Related Messages.......................................................................................................... 11-10
Chapter 12 File Transfer
Transferring Files to an External Device........................................................................... 12-1
Wi-Fi (Optional).................................................................................................................12-2
Installing or Removing a Compact Flash Card .................................................................12-2
Transferring a Full Disclosure File to a Compact
Flash Card......................................................................................................................12-3
Transferring Device Check and Activity Log Files to a Compact Flash Card.................... 12-4
Transferring Files Through the USB Port (R Series Plus Only) ........................................ 12-4
Transferring Full Disclosure Files Through Wi-Fi (R Series Plus Only) ............................ 12-5
Transferring Device Check and Activity Log Files Through Wi-Fi (R Series Plus Only) ... 12-6
Related Wi-Fi Messages ...........................................................................................12-7
Chapter 13 Maintenance
Routine Procedures..........................................................................................................13-2
Daily Visual Inspection ..............................................................................................13-2
Code Readiness Test ............................................................................................... 13-3
Manual Defibrillator Testing............................................................................................... 13-3
Defibrillator Testing with Paddles ............................................................................. 13-4
Defibrillator Testing with Hands-Free Therapy Electrodes .......................................13-5
Pacer Testing ............................................................................................................ 13-6
Recorder Check ........................................................................................................13-6
Code Readiness Log ................................................................................................13-7
Setting Time and Date ..............................................................................................13-9
Cleaning the R Series Unit ....................................................................................... 13-9
Loading Stripchart Paper ........................................................................................ 13-10
Cleaning the Print Head .......................................................................................... 13-11
Operator’s Checklist for R Series Product .............................................................. 13-12
Chapter 14 Troubleshooting
Code-Ready ..............................................................................................................14-1
Monitor ......................................................................................................................14-2
Recorder ...................................................................................................................14-4
Pacer ........................................................................................................................14-4
Defibrillator ................................................................................................................14-5
AC Charger ............................................................................................................... 14-8
CPR ..........................................................................................................................14-8

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
