ZOLL R Series Service Manual

R Series Model Features
9650-0904-01 Rev. N ZOLL R Series Operator’s Guide 1–3
R Series Model Features
The following features are available in the R Series Plus and R Series BLS models. Pacing and
SpO2 monitoring are additional options that may be purchased separately.
Feature BLS Model Plus Model
Real CPR Help

See-Thru CPR

Perfusion Performance Indicator™

OneStep system

OneStep cable

OneStep ECG leads cable
(3-lead set)

OneStep Cable Manager

Code Readiness testing system

Integrated hands free electrode
mounting

Rectilinear Biphasic Waveform

Universal operating system

Defib activity log

Corrective voice prompts

5.8 Ah rechargeable lithium-ion
battery

3 lead ECG cable

90mm strip chart writer

Integrated AC power

Built-in test port

Compact Flash card slot

USB device port

Wi-Fi communication software

EtCO
2

NIBP

Optional Items Available in Both Models
Pacing
SpO2

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
