R Series Service Manual

9650-0903-01 Rev. L 1-9

3.0 3 and 5 Leads Test

Tools Needed: Impulse 4000,3 lead adapter (part # 8009-0762-XX) or 3 lead cable, and 5 lead cable. If applicable, test each cable separately.

Test Setup:

1. The R Series unit must be configured to display ECG LEAD OFF message.

2. Connect the lead wires appropriate to each test to the Fluke Biomedical 4000 or equivalent.

Do this... Observe this... Pass/Fail/NA

3.1 Turn the selector switch to MONITOR (for AED

units turn to ON.) Select leads.

ECG LEAD OFF message is not displayed.

ooo

3.2 Disconnect one lead from the Impulse 4000. The ECG LEAD OFF message displays within 3 seconds (if configured).

ooo

3.3 Reconnect the lead. Repeat step 3.2 with the

remaining leads.

Wait for ECG LEAD OFF message to clear from the display (if configured).

ooo

3.4 If applicable, repeat 3.2 and 3.3 for the

remaining cable(s).

NOTE: If heart rate alarm sounds, press and hold the ALARM SUSPEND

button for 3 seconds to disable the alarms.

ooo

Record your results on the Maintenance Test Checklist.
