ZOLL R Series Service Manual

Defibrillator Controls and Indicators
9650-0904-01 Rev. N ZOLL R Series Operator’s Guide 2–9
Figure 2-5. OneStep Cables
OneStep Cable Manager (Optional)
As an option, the OneStep Cable Manager is available to store and organize cables.
Figure 2-6. The R Series with the Optional OneStep Cable Manager (Side View)
OneStep Pacing Cable
OneStep Cable
ECG Connector
Cable Caddy
OneStep Cable
Manager

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
