APPENDIX ASPECIFICATIONS
A–4 www.zoll.com 9650-0904-01 Rev. N
Synchronized
mode
Synchronizes defibrillator discharge to the patient’s R wave. SYNC is
indicated on the display with R wave markers above the ECG waveform on
the screen and stripchart. When ECG is monitored by the device, meets the
DF-80:2003 requirement of 60ms maximum time delay between the peak of
the R wave and the delivery of energy.
Charge controls CHARGE button on front panel and apex paddle.
Paddles Standard apex/sternum paddles. Adult plate slides off to expose smaller
plate for pediatric patients.
Automatic
Defibrillator Test
Verifies defibrillator charging and discharging without removing paddles
from storage wells or with OneStep cable connected to the Test Port or
OneStep electrodes.
Defibrillation
advisory
Evaluates electrode connection and patient ECG to determine if
defibrillation is required.
Shockable rhythms:
• Ventricular fibrillation (VF) with amplitude > 100 V
• Wide-complex ventricular tachycardia (VT) with rates greater than 150
beats per minute (adult), or 200 beats per minute (pediatric).
Refer to “ECG Rhythm Analysis Algorithm Accuracy” on page A-30 for
sensitivity and specificity performance.
CPR Monitoring
Compression
depth
0.75 to 3 inches ±0.25 inches
1.9 to 7.6 cm ±0.6 cm
Compression rate 50 to 150 compressions per minute
ECG Monitoring
Patient connection 3-lead cable, 5-lead cable, paddles, or hands-free therapy electrodes
Input protection Fully defibrillator-proof. Special circuitry prevents distortion of ECG during
pacer pulse.
Implanted
pacemaker spike
display
Dedicated circuitry detects most implanted pacemaker spikes and provides
standard display marker of spike on ECG trace.
Implanted Pulses
Detected
±2 mV to ±700mV amplitude, 0.1ms to 2ms width, with a recharge constant
of 0 to 100ms.
Note: The pacemaker pulse rejection capability for the R Series with
pacemaker pulses alone includes pulses between +/-2mV and +/
-700mV amplitude, with widths between 0.1ms and 2ms and
overshoot from 0 to 100ms.
The pacemaker pulse rejection capability for the R Series with
pacemaker pulses and a normally paced QRS and T wave includes
pulses between +/-2mV and +/-700mV amplitude, with widths
between 0.1ms and 2ms and overshoot from 0 to 100ms.
The pacemaker pulse rejection capability for the R Series with
pacemaker pulses with an ineffectively paced QRS pattern includes
pulses between +/-2mV and +/-700mV amplitude, with widths
between 0.1ms and 2ms and overshoot from 0 to 100ms.
The R Series is not capable of rejecting A-V Sequential pacemaker
pulses.
Bandwidth 0.5 Hz to 21 Hz standard; 0.05 Hz to 150 Hz diagnostic
0.5 Hz to 40 Hz, and 1 Hz to 21 Hz as configurable options
