ZOLL R Series Service Manual

Manual Defibrillator Testing
9650-0912-01 Rev. N ZOLL R Series Operator’s Guide 12–7
Figure 12-1. Code Readiness Test Log Print Display
Figure 12-2. Code Readiness Test Log
Figure 12-3. Code Readiness Test Report
Code Readiness Test Log
Print
Test Return
Prev
Test
Next
Test
Date: 10 NOV 06 00:01:03
Type: Automatic
Defib: OK
Pace: OK
ECG: OK
AC Power: Connected
Battery: OK
30J Self Test: OK
OneStep Cable: OK
Print
Test Log

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
