APPENDIX ASPECIFICATIONS
A–4 www.zoll.com 9650-0912-01 Rev. N
Defibrillation
advisory
Evaluates electrode connection and patient ECG to determine if
defibrillation is required.
Shockable rhythms:
• Ventricular fibrillation (VF) with amplitude > 100 V
• Wide-complex ventricular tachycardia (VT) with rates greater than 150
beats per minute (adult), or 200 beats per minute (pediatric).
Refer to “ECG Rhythm Analysis Algorithm Accuracy” on page A-29 for
sensitivity and specificity performance.
CPR Monitoring
Compression depth 0.75 to 3 inches ±0.25 inches
1.9 to 7.6 cm ±0.6 cm
Compression rate 50 to 150 compressions per minute
ECG Monitoring
Patient connection 3-lead cable, 5-lead cable, paddles, or hands-free therapy electrodes
Input protection Fully defibrillator-proof. Special circuitry prevents distortion of ECG during
pacer pulse.
Implanted
pacemaker spike
display
Dedicated circuitry detects most implanted pacemaker spikes and provides
standard display marker of spike on ECG trace.
Implanted Pulses
Detected
±2 mV to ±700mV amplitude, 0.1ms to 2ms width, with a recharge constant
of 0 to 100ms.
Note: The pacemaker pulse rejection capability for the R Series with
pacemaker pulses alone includes pulses between +/-2mV and +/
-700mV amplitude, with widths between 0.1ms and 2ms and
overshoot from 0 to 100ms.
The pacemaker pulse rejection capability for the R Series with
pacemaker pulses and a normally paced QRS and T wave includes
pulses between +/-2mV and +/-700mV amplitude, with widths
between 0.1ms and 2ms and overshoot from 0 to 100ms.
The pacemaker pulse rejection capability for the R Series with
pacemaker pulses with an ineffectively paced QRS pattern includes
pulses between +/-2mV and +/-700mV amplitude, with widths
between 0.1ms and 2ms and overshoot from 0 to 100ms.
The R Series is not capable of rejecting A-V Sequential pacemaker
pulses.
Bandwidth 0.5 Hz to 21 Hz standard; 0.05 Hz to 150 Hz diagnostic
0.5 Hz to 40 Hz, and 1 Hz to 21 Hz as configurable options
Lead selection I, II, III, aVR, aVL, aVF, V, PADS, PADDLES, INTL PADDLES
P1, P2, P3 with OneStep Pacing electrodes
ECG size relative
scale factor
x0.5, x1, x1.5, x2 or x3
Current value shown on display.
Heart rate range 30 to 300 beats per minute
Heart rate accuracy ±5%
Heart rate alarm Screen icon indicates activated/deactivated status. User selectable.
Tachycardia: 60 to 280 beats per minute
Bradycardia: 20 to 100 beats per minute
Tall T-wave
Rejection
<
0.8 mV
