R Series Service Manual
9650-0903-01 Rev. L 1-43
3
Not all simulators have a setting of 93mmHg, check the simulators user's manual for recommendations.
4
These values only apply for test set-ups utilizing the BP Pump 2 Simulator. Variations of the test set-up or different simulators may produce readings outside
the provided values and will require end-user facility to establish the appropriate offset and tolerances. Please contact ZOLL Technical Support if you require
assistance establishing the offset of the simulator and test set-up that you are utilizing.
Do this... Observe this... Pass/Fail
24.1 Turn the selector switch to MONITOR mode.
(For AED units, turn the selector switch to ON
and select Manual mode.)
The R Series powers on in MONITOR mode.
24.2 Ensure that the LEADS parameters is set to
PADS (default).
If necessary, press the LEADS button to cycle
through the values to select PADS.
The R Series displays PADS in the Lead selection field on the monitor.
oo
24.3 Press the NIBP button on the R Series front
panel.
The R Series initiates the blood pressure measurement cycle and displays the
following measurements
4
:
• systolic pressure (126 ± 5 mmHg)
• diastolic pressure (84 ± 5 mmHg)
• mean pressure (98 ± 5 mmHg)
oo
24.4 Press the Param softkey.
24.5 Select the Trend softkey, then select the NIBP
Trend softkey.
The R Series displays a summary of the NIBP measurements, including the
pulse rate reading (in the range of 77 - 85 bpm).
oo
Record your results on the Maintenance Test Checklist.
