ZOLL R Series Service Manual

R Series Rectilinear Biphasic Waveform Characteristics
9650-0912-01 Rev. N ZOLL R Series Operator’s Guide A–23
Figure A-18. Rectilinear Biphasic Waveform at 4 Joules
Figure A-19. Rectilinear Biphasic Waveform at 3 Joules
-5
-4
-3
-2
-1
0
1
2
3
4
5
024681012
ms
A
25 Ohm
50 Ohm
75 Ohm
100 Ohm
125 Ohm
150 Ohm
175 Ohm
200 Ohm
-4
-3
-2
-1
0
1
2
3
4
5
024681012
ms
A
25 Ohm
50 Ohm
75 Ohm
100 Ohm
125 Ohm
150 Ohm
175 Ohm
200 Ohm

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
