ZOLL R Series Service Manual

APPENDIX BR SERIES ACCESSORIES
B–2 www.zoll.com 9650-0912-01 Rev. N
Cables
OneStep Cable (100-240V, 50/60Hz)
OneStep Pacing Cable (100-240V, 50Hz)
AAMI 3-Lead Wire ECG Patient Cable (6’ or 12’)
AAMI 3-Lead Wire ECG Patient Cable, ESU
IEC 3-Lead ECG Patient Cable
AAMI 5-Lead Wire ECG Patient Cable
IEC 5-Lead Wire ECG Patient Cable
Power Cord Extension Cable (12”)
AC power cord
Batteries and Chargers
SurePower Charger
SurePower Battery
SpO
2
Sensors and Cables
LNCS Adtx
Single use sensor for patients > 30 kg
LNCS Pdtx
Single use sensor for Pediatrics and Slender Adults
10-50 kg
LNCS Inf-L
Single use sensor for Infants 3-20 kg
LNCS Neo-L
Single use sensor for Neonates < 3 kg
LNCS NeoPt-L
Single use sensor for Neonates < 1 kg (Pre-term)
LNCS DCI
Reusable sensor for Adults and Pediatrics > 30 kg
LNCS DCIP
Reusable sensor for Pediatrics 10-50 kg
LNC-4 4’ Reusable Patient Cable
LNC-10 10’ Reusable Patient Cable
LNC Ext LNC Extension Cable, DB-9 Termination, 4ft
LNCS-to-LNOP Adapter Cable, LNCS Sensor to LNOP Patient Cable
LNOP DC-12 LNOP Adult Reusable Direct Connect 12’ Cable
EtCO
2
Sensors and Cables
CAPNOSTAT 5 CO
2
Sensor and Cable
SPU
Pediatric/Adult Airway Adapter
SPU Neonatal/Pediatric Airway Adapter

ZOLL R Series Specifications

General

Defibrillator Type	Manual and AED
Pacing	Yes
ECG Monitoring	Yes
SpO2 Monitoring	Yes
FAST-SpO2	Yes
IP Rating	IP55
Defibrillator Waveform	Biphasic
Energy Levels	1-360 Joules
Display	LCD
Pacer Type	Demand
Pacer Rate	30-180 ppm
Pacer Output	0 – 140 mA
EtCO2 Monitoring	Optional
NIBP Monitoring	Optional
Temperature Monitoring	Optional
Printer	Integrated
Battery Type	Lithium-ion
CPR Feedback	Yes
Data Storage	Internal memory
Connectivity	USB
