ZXR10 2920/2928/2952
(V1.0) Access Switch User Manual （Volume I）
128 Confidential and Proprietary Information of ZTE CORPORATION
Configuring L2 ACL
This topic describes the configuration of L2 ACL.
For the configuration of L2 ACL, perform the following steps.
1. To enter in L2 ACL configuration, use command config
acl link number <acl-number> in global configuration
mode. This is shown in
Table 192.
TABLE 192 CONFIG ACL LINK COMMAND
Format Mode Function
config acl link
number <acl-
number>
global config This enters into L2
ACL configuration
mode
Result: This enters into L2 ACL configuration mode.
2. To configure the rules of ACL, use command rule <rule-
id> {permit | deny} {ip | arp | other | any } [ether-
type <protocol-number>] [<dsap-ssap>][cos] [source-
vlanid] {<source-mac wildcard> | any |<destination-mac
wildcard> | any} in ACL config mode. This is shown in
Table 193
TABLE 193 RULE COMMAND
Format Mode Function
rule <rule-id>
{permit | deny}
{ip | arp | other |
any } [ether-type
<protocol-
number>] [<dsap-
ssap>][cos]
[source-vlanid]
{<source-mac
wildcard> | any
|<destination-mac
wildcard> | any}
ACL config
This configures ACL
rules
Result: This configures ACL rules.
E
ND OF STEPS
L2 ACL has been configured.
Configuring Hybrid ACL
This topic describes the configuration of Hybrid ACL.
For the configuration of Hybrid ACL, perform the following steps.
Purpose
Steps
Steps
Purpose
Steps

Zte ZXR10 2928 Specifications

General

MAC Address Table Size	16K
VLAN	4K
Jumbo Frame	9K
Power Supply	AC 100-240V, 50/60Hz
Power Consumption	< 30W
Dimensions	440mm x 200mm x 44mm
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Ports	24 x 10/100/1000Base-T ports, 4 x GE SFP ports
