Chapter 7 Service Configuration
Confidential and Proprietary Information of ZTE CORPORATION 77
Format Mode Function
{ingress|egress}
Result: This deletes destination port.
2. To display the port mirroring configuration, use command
show mirror in global configuration mode. This is shown
in
Table 63.
TABLE 63 SHOW MIRROR COMMAND
Format Mode Function
show mirror
Global
config
This displays port mirroring
configuration
Result: This displays port mirroring configuration.
E
ND OF STEPS]
Port mirroring is configured on ZXR10 2920/2928/2952.
To mirror data packets received by port 1 and port 16 onto the
monitoring port 10, configuration is as follows:
zte(cfg)# set mirror add dest-port 10 ingress
zte(cfg)# set mirror add source-port 1, 16 ingress
Use the command show mirror to view the port mirroring
configuration.
zte(cfg)#show mirror
ingress mirror infomation
---------------------------
source port: 1 16
dest port : 10
egress mirror infomation
---------------------------
source port: none
dest port : none
zte(cfg)#
To mirror the data packets received by port 2 and port 3 onto
the monitoring port 4, configuration is as follows:
zte(cfg)# set mirror add dest-port 4 egress
zte(cfg)# set mirror add source-port 2, 3 egress
VLAN
Result
Example
