Zte ZXR10 2928 User Manual

Chapter 8 Access Service
Confidential and Proprietary Information of ZTE CORPORATION 177
zte(cfg-nas)#radius isp 188 enable
zte(cfg-nas)#radius isp 188 add authentication 10. 40.
92. 212
zte(cfg-nas)#radius isp 188 add authentication 10. 40.
92. 215
zte(cfg-nas)#radius isp 188 add accounting 10. 40. 92.
215
zte(cfg-nas)#radius isp 188 add accounting 10. 40. 92.
212
zte(cfg-nas)#radius isp 188 sharedsecret 123456
zte(cfg-nas)#radius isp 188 client 10. 40. 92. 100
zte(cfg-nas)#radius isp 188 defaultisp enable
zte(cfg-nas)#show radius 188
Client : 10. 40. 92. 100
IspName : 188
DefaultIsp : Yes Description :
FullAccounts : No SharedSecret:
123456
Authentication servers Auth-port
---------------------- ---------
10. 40. 92. 212 1812
10. 40. 92. 215 1812
Accounting servers Acct-port
---------------------- ---------
10. 40. 92. 215 1813
10. 40. 92. 212 1813
zte(cfg-nas)#
QinQ Overview
QinQ is IEEE 802. 1Q tunneling protocol and is also called VLAN
stacking. QinQ technology is the addition of one more VLAN
tag (outer tag) to the original VLAN tag (inner tag). Outer tag
can shield the inner tag.
QinQ does not need protocol support. Simple Layer 2 Virtual
Private Network (L2VPN) can be realized through QinQ. QinQ
is especially suitable for small-size LAN that takes layer 3 switch
as its backbone.
Figure 33 shows typical networking of the QinQ technology.
Port connected to user network is called Customer port. Port
connected to ISP network is called Uplink port. Edge access
equipment of ISP network is called Provider Edge (PE).
QinQ
description

Zte ZXR10 2928 Specifications

General

MAC Address Table Size	16K
VLAN	4K
Jumbo Frame	9K
Power Supply	AC 100-240V, 50/60Hz
Power Consumption	< 30W
Dimensions	440mm x 200mm x 44mm
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Ports	24 x 10/100/1000Base-T ports, 4 x GE SFP ports
