Zte ZXR10 2928 User Manual

Chapter 5 Usage and Operation
Confidential and Proprietary Information of ZTE CORPORATION 41
For the configuration of user mode, perform the following steps.
1. When using HyperTerminal mode to log on to system,
system enters into user mode automatically.
Result: The prompt character in the user mode is the host
name followed by “>”, as shown below:
zte>
Note: By default host name is zte. Modify the host name
by using the command hostname.
2. In the user mode, execute the command exit to exit the
switch configuration.
3. In the user mode, execute the command show to display
the system configuration and operation information.
Note: The command show can be executed in any mode.
E
ND OF STEPS
User mode has been configured.
Configuring Global Mode
This topic describes the global configuration mode.
For the configuration of global mode, perform the following
steps.
1. In user mode, enter the enable command and the
corresponding password to enter the global configuration
mode, as follows:
zte>enable
Password:***
zte(cfg)#
2. In the global configuration mode, various functions of the
switch can be configured. Use command set user
local|radius <name> admin-password [<string>] to set
the password for entering the global configuration mode to
prevent the login of unauthorized users.
Result: This sets the password for entering the global
configuration mode.
3. To return to the user mode from the global configuration
mode, use the exit command.
E
ND OF STEPS
Global mode has been configured.
Steps
Result
Purpose
Steps
Result

Zte ZXR10 2928 Specifications

General

MAC Address Table Size	16K
VLAN	4K
Jumbo Frame	9K
Power Supply	AC 100-240V, 50/60Hz
Power Consumption	< 30W
Dimensions	440mm x 200mm x 44mm
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Ports	24 x 10/100/1000Base-T ports, 4 x GE SFP ports
