Zte ZXR10 2928 User Manual

ZXR10 2920/2928/2952
(V1.0) Access Switch User Manual （Volume I）
256 Confidential and Proprietary Information of ZTE CORPORATION
Format Mode Function
to cluster
Result: This displays candidate switches that can be added
to cluster.
3. To display cluster member information, use command
show group member [<1-255>] in global config mode.
This is shown in
Table 427.
TABLE 427 SHOW GROUP MEMBER COMMAND
Format Mode Function
show group
member [<1-
255>]
global config This displays cluster
member
information
Result: This displays cluster member information.
E
ND OF STEPS
Cluster configuration and member information has been
displayed.
This example describes the initial configuration of switches is
default configuration. Set the VLAN where public network IP
address of command switch in cluster is located to 2525, IP
address to 100. 1. 1. 10/24, gateway address to 100. 1.
1. 1, cluster management VLAN to 4000, private address pool
to 192. 168. 1. 0/24, and IP address of TFTP Server of
whole cluster to 110. 1. 1. 2. This is shown in
Figure 42.
Detail configuration is as follows:
Configure public network IP address of command switch and
gateway.
WYXX(cfg)#set vlan 2525 enable
WYXX(cfg)#set vlan 2525 add port 1-16 tag
WYXX(cfg)#config router
WYXX(cfg-router)#set ipport 25 ipaddress 100. 1. 1.
10/24
WYXX(cfg-router)#set ipport 25 vlan 2525
WYXX(cfg-router)#set ipport 25 enable
WYXX(cfg-router)#iproute 0. 0. 0. 0/0 100. 1. 1.
1
Result
Example

Zte ZXR10 2928 Specifications

General

MAC Address Table Size	16K
VLAN	4K
Jumbo Frame	9K
Power Supply	AC 100-240V, 50/60Hz
Power Consumption	< 30W
Dimensions	440mm x 200mm x 44mm
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Ports	24 x 10/100/1000Base-T ports, 4 x GE SFP ports
