ZXR10 2920/2928/2952
(V1.0) Access Switch User Manual Volume I
44 Confidential and Proprietary Information of ZTE CORPORATION
zte(cfg)#config group
zte(cfg-group)#
Note: In the cluster management configuration mode,
configuration of switch cluster management service.
2. To return to the global configuration mode from the cluster
management configuration mode, use command exit or
press Ctrl+Z.
E
ND OF STEPS
Cluster management is configured.
Configuring Basic ACL
This topic describes the basic ACL configuration mode.
For the configuration of basic ACL, perform the following steps.
1. In the global configuration mode, execute command config
acl basic number <1-99> to enter into basic ACL
configuration mode, as shown below:
zte(cfg)#config acl basic number 10
zte(basic-acl-group)#
Note: In the basic ACL configuration mode, it is possible to
add, delete, move the ACL rule for the specified ACL id.
2. To return to the global configuration mode from basic ACL
configuration mode, use command exit or press Ctrl + Z.
E
ND OF STEPS
Basic ACL is configured.
Configuring Extended ACL
This topic describes the extended ACL configuration mode.
For the configuration of extended ACL, perform the following
steps.
1. In the global configuration mode, execute command config
acl extend number <100-199> to enter into extended ACL
configuration mode, as shown in:
zte(cfg)#config acl extend number 100
zte(extend-acl-group)#
Note: Extended ACL configuration mode includes configuring
ACL parameters and moving ACL rule sequence id.
2. To return to global configuration mode from the extended
ACL configuration mode, use command exit or press Ctrl+Z.
Result
Purpose
Steps
Result
Purpose
Steps
