ZXR10 2920/2928/2952
(V1.0) Access Switch User Manual （Volume I）
14 Confidential and Proprietary Information of ZTE CORPORATION
 Two fixed 1000BASE-X interface.
 One console port is to realize the management and
configuration of various services.
There are 48 indicators on the front panel of the ZXR10 2952,
indicating the status of the 48 10/100 Base-T ports. Every
interface has one indicators, indicating LNK and ACT. Four
indicators show two 10/100/1000 BASE-T port & two indicators
for each port showing LNK & LNK/ACT status;two indicators
indicate 2 1000Base-X port, each port with one indicator,
showing LNK/ACT status of the port;two system indicators show
power indicator(PWR) & running indicator(RUN) .
 System indicators include power indicator (PWR) and running
indicator (RUN).
f After the system is powered on, PWR indicator is on and
the RUN indicator is off.
f BootROM starts to load the version. If the version is
unavailable, the states of indicators do not change. If the
version is loaded normally, the RUN indicator flashes at
1Hz.
f If the power indicator (PWR) is flashing , it indicates that
the switch is the main or standby role of the stack
system. Flashing in the same frequency with RUN shows
it is the main equipment. Flashing in the half frequency
with RUN shows it is the standby equipment.
 48 indicators respond to 48 10/100 Base-T port. Every port
has 1 indicator indicating LNK/ACT. If the link indicator is on,
it indicates that the LINK is normal. If the indicator is
flashing, it indicates that data sending or receiving is
underway.
 There are 2 indicators, indicating the status of the two 1000
Base-X ports. Every port has 1 indicator: If the link indicator
is on, it indicates that the LINK is normal. If the indicator is
flashing, it indicates that data sending or receiving is
underway.
 4 interface indicators correspond to the two
10/100/1000Base-T interfaces. Every interface has two
indicators. When one of the indicators is on, it indicates
that the LINK is normal. When the other indicator is on, it
indicates that the LINK is normal. If the indicator is flashing,
it indicates that data sending or receiving is underway.
ZXR10 2928-FI
FGEI 、 FGFI 、 FGFE can be chosen for ZXR10 2920/2928
according to the practical networking. Corresponding types &
functions are shown in
table5 ZXR10 .
Indicators
Sub-board

Zte ZXR10 2928 Specifications

General

MAC Address Table Size	16K
VLAN	4K
Jumbo Frame	9K
Power Supply	AC 100-240V, 50/60Hz
Power Consumption	< 30W
Dimensions	440mm x 200mm x 44mm
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Ports	24 x 10/100/1000Base-T ports, 4 x GE SFP ports
