ZXR10 2920/2928/2952
(V1.0) Access Switch User Manual （Volume I）
148 Confidential and Proprietary Information of ZTE CORPORATION
FIGURE 28 PLVAN CONFIGURATION EXAMPLE
p1
p2
Switch
p3
p16
Server
Configuration
zte(cfg)#set pvlan session 1 add promis port 16 isolate-
port 1-3
zte(cfg)#show pvlan
pvlan session : 1
promiscuous-port: 16
isolated-port : 1-3
isolated-trunk :
pvlan session : 2
promiscuous-port:
isolated-port :
isolated-trunk :
pvlan session : 3
promiscuous-port:
isolated-port :
isolated-trunk :
pvlan session : 4
promiscuous-port:
isolated-port :
isolated-trunk :
zte(cfg)#
In PLVAN 2 session add trunk 16 with isolation port trunk 1, 2
and 3.
