ZXR10 2920/2928/2952
(V1.0) Access Switch User Manual （Volume I）
268 Confidential and Proprietary Information of ZTE CORPORATION
FIGURE 49 PORT CONFIGURATION INFORMATION
f The page shows the following information of the port:
Parameters Description
Media Type Media type of the port
Port Name Port name
Admin Statu Port Enable
Work Mode Work mode of the port
Auto Neg Work mode of the port that is work
speed and duplex
PVID VLAN ID is default on the port
Flow Control Flow control enable on the port
Multi Filter Multicast filtration enable on the port
Mac Limit Limit the MAC address learning on the
port
Security Security enable on the port
Speed Advertise Speed advertise on the port
3. For single port configuration, click Config button in the port
row in the port configuration information page list to open
the configuration page of the port need to be configured, as
shown in
Figure 50.
