1-13
Figure 1-11 802.1X configuration on a port
Table 1-4 lists port 802.1X configuration items.
Table 1-4 Port 802.1X configuration items
Item Description
Port
Select the port to be enabled with 802.1X authentication.
Only ports not enabled with 802.1X authentication are available.
Port Control
Specify the 802.1X port access control method for the port, which can be
MAC Based or Port Based.
Port Authorization
Specify the 802.1X authorization mode for the port.
Options include:
z Auto: The initial state on the specified port is unauthorized and
becomes authorized when the authentication is successful. This mode
is commonly applied.
z Force-Authorized: The specified port is always in the authorized state.
z Force-Unauthorized: The specified port is always in the unauthorized
state.
Max Number of Users Specify the maximum number of users allowed on the specified port.
HandShake
Specify whether to enable the online user handshake function, which is
used by the device to periodically detect whether a user is still online.
Re-authentication Specify whether to enable periodic re-authentication on the specified port.
Guest VLAN
Currently, switch 2900 series do not support Guest VLAN function.
Return to
802.1X configuration procedure.
