2-26
Figure 2-23 The page for configuring port priority
Figure 2-24 The page for modifying port priority
Table 2-22 describes the port priority configuration items.
Table 2-22 Port priority configuration items
Item Description
Interface The interface to be configured.
Priority Set a local precedence value for the port.
Trust Mode
Select a priority trust mode for the port, which can be
z Untrust: where packet priority is not trusted.
z CoS: where the 802.1p precedence of the incoming packets is
trusted and used for priority mapping.
z DSCP: where the DSCP precedence of the incoming packets is
trusted and used for priority mapping.
