3-9
Figure 3-10 Create a policy
z Type the policy name policy1.
z Click Create.
# Configure classifier-behavior associations for the policy.
z Click Setup. Perform configuration as shown in Figure 3-11.
Figure 3-11 Configure classifier-behavior associations for the policy
z Select policy1.
z Select class1 in the Classifier Name drop-down list.
z Select behavior1 in the Behavior Name drop-down list.
z Click Apply.
# Apply the QoS policy in the inbound direction of GigabitEthernet 1/0/1.
z Select QoS > Port Policy from the navigation tree and click the Setup tab. Perform configuration
as shown in
Figure 3-12.
