Operation and Maintenance
237
Aastra 470 ab R3.0
syd-0337/1.5 – R3.0 – 05.2013
Using the microSD card
Note:
The microSD-Card must be handled very carefully. The contacts must be
free of dust, moisture, grease, etc. Do not store the card where it is hot
(e.g. in direct sunlight). Do not bend the card; bending may destroy the
contacts.
1. Switch off the communication server.
2. Open the battery compartment and remove the battery.
3. Push the card holder downward and carefully angle the cover slightly upward
(see Fig. 83 on the left).
Warning
Never touch the visible shiny gold contacts! Electrostatic discharge
may damage the device.
4. Place the card in the holder (with the contact surfaces facing downward and the
card cut-outs facing left).
5. Close the card holder again and push it carefully upward until it engages.
6. Only for Aastra 620d, Aastra 630dwith black card holders!
Take the provided protective cover of the card and place it over the card holder
(see Fig. 83 on the right).
Note:
For Aastra 620d, Aastra 630d mwith white card holders or for
Aastra 622d, Aastra 632d and Aastra 650c do not use the protective
cover.
7. Insert the battery and close the battery compartment.
Fig. 83 microSD card
