ABB ACS880 - Motor

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
1 = Force mode: Force AO1 to value of parameter 14.78
AO1 force data.
AO1b0
Reservedb1…15
1 = 10000h…FFFFh
- / real32
(Visible when 14.1 Module 1 type = FAIO-01)
Displays the value of AO1 in mA.
This parameter is read-only.
AO1 actual value14.76
1000 = 1 mA / 1000 =
1 mA
Value of AO1.0.000 ... 22.000 mA
Zero / uint32
(Visible when 14.1 Module 1 type = FAIO-01)
Selects a signal to be connected to analog output AO1.
Alternatively, sets the output to excitation mode to feed a
constant current to a temperature sensor.
AO1 source14.77
0NoneZero
1
1.1 Motor speed used (page 136).
Motor speed used
3
1.6 Output frequency (page 136).
Output frequency
4
1.7 Motor current (page 136).
Motor current
6
1.10 Motor torque (page 136).
Motor torque
7
1.11 DC voltage (page 136).
DC voltage
8
1.14 Output power (page 137).
Power inu out
10
23.1 Speed ref ramp input (page 271).
Speed ref ramp in
11
23.2 Speed ref ramp output (page 271).
Speed ref ramped
12
24.1 Used speed reference (page 278).
Speed ref used
13
26.2 Torque reference used (page 296).
Torq ref used
14
28.2 Frequency ref ramp output (page 305).
Freq ref used
16
40.1 Process PID output actual (page 375).
Process PID out
17
40.2 Process PID feedback actual (page 375).
Process PID fbk
18
40.3 Process PID setpoint actual (page 375).
Process PID act
19
40.4 Process PID deviation actual (page 375).
Process PID dev
See Terms and abbreviations (page 132).
Other
20The output is used to feed an excitation current to 1…3
Pt100 sensors. See section Motor thermal
protection (page 90).
Force Pt100
excitation
21The output is used to feed an excitation current to a KTY84
sensor. See section Motor thermal protection (page 90).
Force KTY84
excitation
22The output is used to feed an excitation current to 1…3
PTC sensors. See section Motor thermal
protection (page 90).
Force PTC excitation
23The output is used to feed an excitation current to 1…3
Pt1000 sensors. See section Motor thermal
protection (page 90).
Force Pt1000
excitation
37
13.91 AO1 data storage.
AO1 data storage
220 Parameters
