ABB ACS880 - Basics of the Embedded Fieldbus Interface

Function/InformationSetting for fieldbus
control
Parameter
Connect the bits of the storage parameter
(10.99 RO/DIO control word) to the digital
input/outputs of the drive.
Feedback data storage40.8 Set 1 feedback 1
source
Setpoint data storage40.16 Set 1 setpoint 1
source
SYSTEM CONTROL INPUTS
Saves parameter value changes (including
those made through fieldbus control) to
permanent memory.
Save (reverts to Done)96.7 Parameter save manu-
ally
Basics of the embedded fieldbus interface
The cyclic communication between a fieldbus system and the drive consists of 16-bit
data words or 32-bit data words (with the transparent control profiles).
The diagram below illustrates the operation of the embedded fieldbus interface. The
signals transferred in the cyclic communication are explained further below the diagram.
592 Fieldbus control through the embedded fieldbus interface (EFB)
