ABB ACS880 - Parameter Group Summary

Parameter group summary
PageContentsGroup
136
Basic signals for monitoring the drive.
1 Actual values
142
Values of references received from various sources.
3 Input references
144
Information on warnings and faults that occurred last.
4 Warnings and faults
153
Various run-time-type counters and measurements related to drive
maintenance.
5 Diagnostics
155
Drive control and status words.
6 Control and status words
171
Information on drive hardware, firmware and application program.
7 System info
175
Configuration of digital inputs and relay outputs.
10 Standard DI, RO
182
Configuration of digital input/outputs and frequency inputs/outputs.
11 Standard DIO, FI, FO
188
Configuration of standard analog inputs.
12 Standard AI
193
Configuration of standard analog outputs.
13 Standard AO
199
Configuration of I/O extension module 1.
14 I/O extension module 1
226
Configuration of I/O extension module 2.
15 I/O extension module 2
232
Configuration of I/O extension module 3.
16 I/O extension module 3
238
Selection of local and external control location sources and operating
modes.
19 Operation mode
241
Start/stop/direction and run/start/jog enable signal source selection;
positive/negative reference enable signal source selection.
20 Start/stop/direction
251
Start and stop modes; emergency stop mode and signal source
selection; DC magnetization settings; autophasing mode selection.
21 Start/stop mode
262
Speed reference selection; motor potentiometer settings.
22 Speed reference selection
271
Speed reference ramp settings (programming of the acceleration and
deceleration rates for the drive).
23 Speed reference ramp
278
Speed error calculation; speed error window control configuration;
speed error step.
24 Speed reference
conditioning
285
Speed controller settings.
25 Speed control
296
Settings for the frequency reference chain.
26 Torque reference chain
305
Settings for the frequency reference chain.
28 Frequency reference chain
314
Settings for the DC voltage reference chain.
29 Voltage reference chain
319
Drive operation limits.
30 Limits
330
Configuration of external events; selection of behavior of the drive
upon fault situations.
31 Fault functions
341
Configuration of signal supervision functions 1…3.
32 Supervision
345
Configuration of maintenance timers/counters.
33 Generic timer & counter
353
Motor thermal protection settings such as temperature measurement
configuration, load curve definition and motor fan control configuration.
35 Motor thermal protection
367
Peak value and amplitude logger settings.
36 Load analyzer
372
Settings for user load curve.
37 User load curve
375
Parameter values for process PID control.
40 Process PID set 1
Parameters 133
