ABB ACS880 - Frequency Reference Chain

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Settings for the frequency reference chain.Frequency
reference chain
28
See the control chain diagrams 636 and 637.
- / real32Displays the used frequency reference before ramping.
See the control chain diagram on page 637.
Frequency ref ramp
input
28.1
This parameter is read-only.
- / -Frequency reference before ramping. For scaling, see
parameter 46.2.
-598.00 ... 598.00 Hz
- / real32Displays the final frequency reference (after selection,
limitation and ramping). See the control chain diagram on
page 637.
Frequency ref ramp
output
28.2
This parameter is read-only.
- / -
Final frequency reference. For scaling, see parameter 46.2.
-598.00 ... 598.00 Hz
Zero / uint32Selects frequency reference source 1.
Two signal sources can be defined by this parameter and
28.12 Frequency ref2 source. A digital source selected by
Frequency ref1
source
28.11
28.14 Frequency ref1/2 selection can be used to switch
between the two sources, or a mathematical function (28.13
Frequency ref1 function) applied to the two signals to create
the reference.
…
…
0
AI
FB
Other
28.11
28.12
28.13
28.90
28.91
28.14
28.92
Ref1
ADD
SUB
MUL
MIN
MAX
0
AI
FB
Other
0
1
0None.Zero
1
12.12 AI1 scaled value (page 189).
AI1 scaled
2
12.22 AI2 scaled value (page 191).
AI2 scaled
4
3.5 FB A reference 1 (page 142).
FB A ref1
5
3.6 FB A reference 2 (page 142).
FB A ref2
8
3.9 EFB reference 1 (page 142).
EFB ref1
9
3.10 EFB reference 2 (page 142).
EFB ref2
10
3.11 DDCS controller ref 1 (page 142).
DDCS ctrl ref1
11
3.12 DDCS controller ref 2 (page 142).
DDCS ctrl ref2
12
3.13 M/F or D2D ref1 (page 143).
M/F reference 1
13
3.14 M/F or D2D ref2 (page 143).
M/F reference 2
15
22.80 Motor potentiometer ref act (output of the motor
potentiometer).
Motor potentiometer
Parameters 305
