ABB ACS880 - Page 189

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
4
Drive generates a warning (A8A0 AI Supervised Warning)
and sets the speed to the speed defined by parameter
22.41 Speed ref safe (or 28.41 Frequency ref safe when
frequency reference is being used).
WARNING!
Make sure that it is safe to continue operation in
case of a communication break.
Speed ref safe
- / uint16Specifies the analog input limits to be supervised. See
parameter 12.3 AI supervision function.
AI supervision
selection
12.4
1 = Minimum limit supervision of AI1 active.AI1 < MINb0
1 = Maximum limit supervision of AI1 active.AI1 > MAXb1
1 = Minimum limit supervision of AI2 active.AI2 < MINb2
1 = Maximum limit supervision of AI2 active.AI2 > MAXb3
Reservedb4…15
1 = 10000h…FFFFh
- / uint16Activates analog input supervision separately for each
control location (see section Local control vs. external
control (page 23)).
The parameter is primarily intended for analog input
supervision when the input is connected to the application
program and not selected as a control source by drive
parameters.
AI supervision force12.5
1 = AI1 supervision active when EXT1 is being used.AI1 Ext 1b0
1 = AI1 supervision active when EXT2 is being used.AI1 Ext 2b1
1 = AI1 supervision active when local control is being used.AI1 Localb2
Reservedb3
1 = AI2 supervision active when EXT1 is being used.AI2 Ext 1b4
1 = AI2 supervision active when EXT2 is being used.AI2 Ext 2b5
1 = AI2 supervision active when local control is being used.AI2 Localb6
Reservedb7…15
1 = 10000 0000b…0111
0111b
- / real32Displays the value of analog input AI1 in mA or V
(depending on whether the input is set to current or voltage
by a hardware setting).
This parameter is read-only.
AI1 actual value12.11
1000 = 1 mA or V /
1000 = 1 mA or V
Value of analog input AI1.-22.000 ... 22.000 mA
or V
- / real32Displays the value of analog input AI1 after scaling. See
parameters 12.19 AI1 scaled at AI1 min and 12.20 AI1
scaled at AI1 max.
This parameter is read-only.
AI1 scaled value12.12
Parameters 189
