ABB ACS880 - Page 266

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Not selected / uint32
When bit 0 of parameter 22.21 Constant speed function is
0 (Separate), selects a source that activates constant
speed 3.
When bit 0 of parameter 22.21 Constant speed function is
1 (Packed), this parameter and parameters 22.22 Constant
speed sel1 and 22.23 Constant speed sel2 select three
sources that are used to activate constant speeds. See
table at parameter 22.22 Constant speed sel1.
For the selections, see parameter 22.22 Constant speed
sel1.
Constant speed sel322.24
300.00 rpm / real32Defines constant speed 1 (the speed the motor will turn
when constant speed 1 is selected).
Constant speed 122.26
- / -
Constant speed 1. For scaling, see parameter 46.1.
-30000.00 ...
30000.00 rpm
0.00 rpm / real32Defines constant speed 2.Constant speed 222.27
- / -
Constant speed 2. For scaling, see parameter 46.1.
-30000.00 ...
30000.00 rpm
0.00 rpm / real32Defines constant speed 3.Constant speed 322.28
- / -
Constant speed 3. For scaling, see parameter 46.1.
-30000.00 ...
30000.00 rpm
0.00 rpm / real32Defines constant speed 4.Constant speed 422.29
- / -
Constant speed 4. For scaling, see parameter 46.1.
-30000.00 ...
30000.00 rpm
0.00 rpm / real32Defines constant speed 5.Constant speed 522.30
- / -
Constant speed 5. For scaling, see parameter 46.1.
-30000.00 ...
30000.00 rpm
0.00 rpm / real32Defines constant speed 6.Constant speed 622.31
- / -
Constant speed 6. For scaling, see parameter 46.1.
-30000.00 ...
30000.00 rpm
0.00 rpm / real32Defines constant speed 7.Constant speed 722.32
- / -
Constant speed 7. For scaling, see parameter 46.1.
-30000.00 ...
30000.00 rpm
- / real32Defines a safe speed reference value that is used with
supervision functions such as
•
12.3 AI supervision function
•
49.5 Communication loss action
•
50.2 FBA A comm loss func
•
50.32 FBA B comm loss func
•
58.14 Communication loss action.
Speed ref safe22.41
- / -
Safe speed reference. For scaling, see parameter 46.1.
-30000.00 ...
30000.00 rpm
0.00 rpm / real32Defines the speed reference for jogging function 1. For
more information on jogging, see page 61.
Jogging 1 ref22.42
266 Parameters
