ABB ACS880 - D2 D and DDCS Transmit Data

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Defines the data sent to the DDCS link.D2D and DDCS
transmit data
61
See also parameter group 60 DDCS communication.
Used speed reference
/ uint32
Preselects the data to be sent as word 2 onto the
master/follower link.
See also parameter 61.26 M/F data 2 value.
M/F data 2 selection61.2
For the selections, see parameter 61.1 M/F data 1
selection.
Torque reference act 5
/ uint32
Preselects the data to be sent as word 3 onto the
master/follower link.
See also parameter 61.27 M/F data 3 value.
M/F data 3 selection61.3
For the selections, see parameter 61.1 M/F data 1
selection.
- / uint16Displays the data to be sent onto the master/follower link
as word 1 as an integer.
M/F data 1 value61.25
If no data has been preselected by 61.1 M/F data 1
selection, the value to be sent can be written directly into
this parameter.
- / -Data to be sent as word 1 in master/follower
communication.
0...65535
- / uint16Displays the data to be sent onto the master/follower link
as word 2 as an integer.
M/F data 2 value61.26
If no data has been preselected by 61.2 M/F data 2
selection, the value to be sent can be written directly into
this parameter.
- / -Data to be sent as word 2 in master/follower
communication.
0...65535
- / uint16Displays the data to be sent onto the master/follower link
as word 3 as an integer.
M/F data 3 value61.27
If no data has been preselected by 61.3 M/F data 3
selection, the value to be sent can be written directly into
this parameter.
- / -Data to be sent as word 3 in master/follower
communication.
0...65535
None / uint32
Parameters 61.45…61.50 preselect data to be sent in data
sets 2 and 4 to the external controller. These data sets are
Data set 2 data 1
selection
61.45
used in ModuleBus communication with a “standard drive”
(60.50 DDCS controller drive type = ABB standard drive).
Parameters 61.95…61.100 display the data to be sent to
the external controller. If no data has been preselected,
the value to be sent can be written directly into these
parameters. For example, this parameter preselects the
data for word 1 of data set 2. Parameter 61.95 Data set 2
data 1 value displays the selected data in integer format.
If no data is preselected, the value to be sent can be written
directly into parameter 61.95.
0None.None
1Control Word (16 bits)CW 16bit
4Status Word (16 bits)SW 16bit
5Actual value ACT1 (16 bits)Act1 16bit
Parameters 457
