ABB ACS880 - Standard DIO, FI, FO

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Configuration of digital input/outputs and frequency
inputs/outputs.
Standard DIO, FI,
FO
11
- / uint16Displays the status of digital input/outputs DIO2 and DIO1.
The activation/deactivation delays (if any are specified)
are ignored. A filtering time (for input mode) can be defined
by parameter 11.81 DIO filter time.
DIO status11.1
Example: 0010 = DIO2 is on, DIO1 is off.
This parameter is read-only.
- / uint16Displays the delayed status of digital input/outputs DIO2
and DIO1. This word is updated only after
DIO delayed status11.2
activation/deactivation delays (if any are specified). A
filtering time (for input mode) can be defined by parameter
11.81 DIO filter time.
Example: 0010 = DIO2 is on, DIO1 is off.
This parameter is read-only.
Output / uint16Selects whether DIO1 is used as a digital output or input,
or a frequency input.
DIO1 function11.5
0DIO1 is used as a digital output.Output
1DIO1 is used as a digital input.Input
2DIO1 is used as a frequency input.Frequency
Ready run / uint32Selects a drive signal to be connected to digital input/output
DIO1 when parameter 11.5 DIO1 function is set to Output.
DIO1 output source11.6
0Output is not energized.Not energized
1Output is energized.Energized
2
Bit 1 of 6.11 Main status word (page 156).
Ready run
4
Bit 0 of 6.16 Drive status word 1 (page 156).
Enabled
5
Bit 5 of 6.16 Drive status word 1 (page 156).
Started
6
Bit 1 of 6.17 Drive status word 2 (page 156).
Magnetized
7
Bit 6 of 6.16 Drive status word 1 (page 156).
Running
8
Bit 2 of 6.11 Main status word (page 156).
Ready ref
9
Bit 8 of 6.11 Main status word (page 156).
At setpoint
10
Bit 2 of 6.19 Speed control status word (page 158).
Reverse
11
Bit 0 of 6.19 Speed control status word (page 158).
Zero speed
12
Bit 10 of 6.17 Drive status word 2 (page 156).
Above limit
13
Bit 7 of 6.11 Main status word (page 156).
Warning
14
Bit 3 of 6.11 Main status word (page 156).
Fault
15
Inverted bit 3 of 6.11 Main status word (page 156).
Fault (-1)
16
Bit 13 of 6.16 Drive status word 1 (page 156).
Start request
22
Bit 0 of 44.1 Brake control status (page 395).
Open brake command
23
Bit 11 of 6.16 Drive status word 1 (page 156).
Ext2 active
24
Bit 9 of 6.11 Main status word (page 156).
Remote control
33
Bit 0 of 32.1 Supervision status (page 341).
Supervision 1
182 Parameters
