ABB ACS880 - O Extension Module 3

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Configuration of I/O extension module 3.I/O extension
module 3
16
See also section Programmable I/O extensions (page 33).
Note: The contents of the parameter group vary according
to the selected I/O extension module type.
None / uint16
See parameter 14.1 Module 1 type.
Module 3 type16.1
Slot 1 / uint16
See parameter 14.2 Module 1 location.
Module 3 location16.2
No option / uint16
See parameter 14.3 Module 1 status.
Module 3 status16.3
- / uint16
(Visible when 16.1 Module 3 type = FDIO-01)
See parameter 14.5 DI status.
DI status16.5
- / uint16
(Visible when 16.1 Module 3 type = FIO-11)
See parameter 14.5 DIO status.
DIO status16.5
- / uint16
(Visible when 16.1 Module 3 type = FIO-01)
See parameter 14.5 DIO status.
DIO status16.5
- / uint16
(Visible when 16.1 Module 3 type = FDIO-01)
See parameter 14.6 DI delayed status.
DI delayed status16.6
- / uint16
(Visible when 16.1 Module 3 type = FIO-11)
See parameter 14.6 DIO delayed status.
DIO delayed status16.6
- / uint16
(Visible when 16.1 Module 3 type = FIO-01)
See parameter 14.6 DIO delayed status.
DIO delayed status16.6
10.0 ms / real32
(Visible when 16.1 Module 3 type = FDIO-01)
See parameter 14.8 DI filter time.
DI filter time16.8
10.0 ms / real32
(Visible when 16.1 Module 3 type = FIO-11)
See parameter 14.8 DIO filter time.
DIO filter time16.8
10.0 ms / real32
(Visible when 16.1 Module 3 type = FIO-01)
See parameter 14.8 DIO filter time.
DIO filter time16.8
Input / uint16
(Visible when 16.1 Module 3 type = FIO-11)
See parameter 14.9 DIO1 function.
DIO1 function16.9
Input / uint16
(Visible when 16.1 Module 3 type = FIO-01)
See parameter 14.9 DIO1 function.
DIO1 function16.9
Not energized / uint32
(Visible when 16.1 Module 3 type = FIO-11)
See parameter 14.11 DIO1 output source.
DIO1 output source16.11
Not energized / uint32
(Visible when 16.1 Module 3 type = FIO-01)
See parameter 14.11 DIO1 output source.
DIO1 output source16.11
0.00 s / real32
(Visible when 16.1 Module 3 type = FDIO-01)
See parameter 14.12 DI1 ON delay.
DI1 ON delay16.12
0.00 s / real32
(Visible when 16.1 Module 3 type = FIO-11)
See parameter 14.12 DIO1 ON delay.
DIO1 ON delay16.12
0.00 s / real32
(Visible when 16.1 Module 3 type = FIO-01)
See parameter 14.12 DIO1 ON delay.
DIO1 ON delay16.12
0.00 s / real32
(Visible when 16.1 Module 3 type = FDIO-01)
See parameter 14.13 DI1 OFF delay.
DI1 OFF delay16.13
0.00 s / real32
(Visible when 16.1 Module 3 type = FIO-11)
See parameter 14.13 DIO1 OFF delay.
DIO1 OFF delay16.13
232 Parameters
