ABB ACS880 - Page 201

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / uint16
(Visible when 14.1 Module 1 type = FIO-01)
Displays the delayed status of the digital input/outputs on
the extension module. This word is updated only after
activation/deactivation delays (if any are specified).
Bit 0 indicates the status of DIO1.
Note: The number of active bits in this parameter depends
on the number of digital input/outputs on the extension
module.
Example: 1001b = DIO1 and DIO4 are on, remainder are
off.
This parameter is read-only.
DIO delayed status14.6
10.0 ms / real32
(Visible when 14.1 Module 1 type = FDIO-01)
Defines a filtering time for parameters 14.5 DI status and
14.6 DI delayed status.
DI filter time14.8
10 = 1 ms / 10 = 1 msFiltering time for DI status parameters.0.8 ... 100.0 ms
10.0 ms / real32
(Visible when 14.1 Module 1 type = FIO-11)
Defines a filtering time for parameters 14.5 DIO status and
14.6 DIO delayed status. The filtering time will only affect
the DIOs that are in input mode.
DIO filter time14.8
10 = 1 ms / 10 = 1 msFiltering time for DIO status parameters.0.8 ... 100.0 ms
10.0 ms / real32
(Visible when 14.1 Module 1 type = FIO-01)
Defines a filtering time for parameters 14.5 DIO status and
14.6 DIO delayed status. The filtering time will only affect
the DIOs that are in input mode.
DIO filter time14.8
10 = 1 ms / 10 = 1 msFiltering time for DIO status parameters.0.8 ... 100.0 ms
Input / uint16
(Visible when 14.1 Module 1 type = FIO-11)
Selects whether DIO1 of the extension module is used as
a digital input or output.
DIO1 function14.9
0DIO1 is used as a digital output.Output
1DIO1 is used as a digital input.Input
Input / uint16
(Visible when 14.1 Module 1 type = FIO-01)
Selects whether DIO1 of the extension module is used as
a digital input or output.
DIO1 function14.9
0DIO1 is used as a digital output.Output
1DIO1 is used as a digital input.Input
Not energized / uint32
(Visible when 14.1 Module 1 type = FIO-11)
Selects a drive signal to be connected to digital input/output
DIO1 of the extension module when parameter 14.9 DIO1
function is set to Output.
DIO1 output source14.11
0Output is not energized.Not energized
1Output is energized.Energized
2
Bit 1 of 6.11 Main status word (page 156).
Ready run
4
Bit 0 of 6.16 Drive status word 1 (page 156).
Enabled
5
Bit 5 of 6.16 Drive status word 1 (page 156).
Started
6
Bit 1 of 6.17 Drive status word 2 (page 156).
Magnetized
Parameters 201
