STATE/DescriptionValueNameBit
Drive control location: REMOTE (EXT1 or
EXT2).
1REMOTE9
Drive control location: LOCAL.0
Actual frequency or speed equals or exceeds
supervision limit (set by drive parameter). Valid
in both directions of rotation.
1ABOVE_ LIMIT10
Actual frequency or speed within supervision
limit.
0
SUSER_011
External Run enable signal received.1EXT_RUN_ ENABLE12
No external Run enable signal received.0
Reserved13...15
￭ State transition diagram
The diagram below shows the state transitions in the drive when the drive is using the
ABB Drives profile, and configured to follow the commands of the control word from the
embedded fieldbus interface. The upper case texts refer to the states which are used
in the tables representing the fieldbus Control and Status words. See sections Control
Word (page 596) and Status Word (page 598).
Fieldbus control through the embedded fieldbus interface (EFB) 599
