ABB ACS880 - Page 458

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
6Actual value ACT2 (16 bits)Act2 16bit
See Terms and abbreviations (page 132).
Other
None / uint32Preselects the data to be sent as word 2 of data set 2 to
the external controller.
See also parameter 61.96 Data set 2 data 2 value.
For the selections, see parameter 61.45 Data set 2 data
1 selection.
Data set 2 data 2
selection
61.46
None / uint32
See parameter 61.45 Data set 2 data 1 selection.
Data set 2 data 3
selection
61.47
…………
None / uint32
See parameter 61.45 Data set 2 data 1 selection.
Data set 4 data 3
selection
61.50
None / uint32
Parameters 61.51…61.74 preselect data to be sent in data
sets 11, 13, 15, 17, 19, 21, 23 and 25 to the external
controller.
Parameters 61.101…61.124 display the data to be sent to
the external controller. If no data has been preselected,
the value to be sent can be written directly into these
parameters.
For example, this parameter preselects the data for word
1 of data set 11. Parameter 61.101 Data set 11 data 1
value displays the selected data in integer format. If no
data is preselected, the value to be sent can be written
directly into parameter 61.101.
Data set 11 data 1
selection
61.51
0None.None
1Control Word (16 bits)CW 16bit
4Status Word (16 bits)SW 16bit
5Actual value ACT1 (16 bits)Act1 16bit
6Actual value ACT2 (16 bits)Act2 16bit
See Terms and abbreviations (page 132).
Other
None / uint32Preselects the data to be sent as word 2 of data set 11 to
the external controller.
See also parameter 61.102 Data set 11 data 2 value.
For the selections, see parameter 61.51 Data set 11 data
1 selection.
Data set 11 data 2
selection
61.52
None / uint32Preselects the data to be sent as word 3 of data set 11 to
the external controller.
See also parameter 61.103 Data set 11 data 3 value.
For the selections, see parameter 61.51 Data set 11 data
1 selection.
Data set 11 data 3
selection
61.53
None / uint32
See parameter 61.51 Data set 11 data 1 selection.
Data set 13 data 1
selection
61.54
…………
None / uint32
See parameter 61.51 Data set 11 data 1 selection.
Data set 25 data 3
selection
61.74
458 Parameters
