Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
DI5 / uint32
When bit 0 of parameter 22.21 Constant speed function is
0 (Separate), selects a source that activates constant
speed 1.
When bit 0 of parameter 22.21 Constant speed function is
1 (Packed), this parameter and parameters 22.23 Constant
speed sel2 and 22.24 Constant speed sel3 select three
sources whose states activate constant speeds as follows:
Constant
speed active
Source
defined by
par. 22.24
Source
defined by
par. 22.23
Source
defined by
par. 22.22
None000
Constant
speed 1
001
Constant
speed 2
010
Constant
speed 3
011
Constant
speed 4
100
Constant
speed 5
101
Constant
speed 6
110
Constant
speed 7
111
Constant speed sel122.22
00Not selected
11Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
Source selection See Terms and abbreviations (page 132).
Other [bit]
Not selected / uint32
When bit 0 of parameter 22.21 Constant speed function is
0 (Separate), selects a source that activates constant
speed 2.
When bit 0 of parameter 22.21 Constant speed function is
1 (Packed), this parameter and parameters 22.22 Constant
speed sel1 and 22.24 Constant speed sel3 select three
sources that are used to activate constant speeds. See
table at parameter 22.22 Constant speed sel1.
For the selections, see parameter 22.22 Constant speed
sel1.
Constant speed sel222.23
Parameters 265
