ABB ACS880 - Page 143

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / real32Master/follower reference 1 received from the master. The
value has been scaled according to parameter 60.10 M/F
ref1 type.
See also section Master/follower functionality (page 34).
M/F or D2D ref13.13
1 = 10 / 100 = 1Scaled reference 1 received from master.-30000.00 ...
30000.00
- / real32Master/follower reference 2 received from the master. The
value has been scaled according to parameter 60.11 M/F
ref2 type.
M/F or D2D ref23.14
1 = 10 / 100 = 1Scaled reference 2 received from master.-30000.00 ...
30000.00
- / int32Reference 1 received through fieldbus adapter A as a 32-bit
integer.
FB A reference 1
int32
3.30
- / -Reference 1 from fieldbus adapter A.-2147483648...2147483647
- / int32Reference 2 received through fieldbus adapter A as a 32-bit
integer.
FB A reference 2
int32
3.31
- / -Reference 2 from fieldbus adapter A.-2147483648...2147483647
0 / real32Panel reference defined in the application program.IEC application panel
reference
3.51
1 = 1 / 1 = 1Panel reference in the application program.-100000...100000
Parameters 143
