Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
100 ms / uint16Sets a timeout for master/follower (DDCS) communication.
If a communication break lasts longer than the timeout, the
action specified by parameter 60.9 M/F comm loss function
is taken.
As a rule of thumb, this parameter should be set to at least
3 times the transmit interval of the master.
M/F comm loss
timeout
60.8
- / -Master/follower communication timeout.0...65535 ms
Fault / uint16Selects how the drive reacts to a master/follower
communication break.
M/F comm loss
function
60.9
0No action taken.NoAction
1
The drive generates an A7CB M/F comm loss warning.
This only occurs if control is expected from the
master/follower link, or if supervision is forced using
parameter 60.32 M/F comm supervision force.
WARNING!
Make sure that it is safe to continue operation in
case of a communication break.
Warning
2
Drive trips on 7582 M/F comm loss. This only occurs if
control is expected from the master/follower link, or if
supervision is forced using parameter 60.32 M/F comm
supervision force.
Fault
3
Drive trips on 7582 M/F comm loss. This occurs even
though no control is expected from the master/follower link.
Fault always
Auto / uint16Selects the type and scaling of reference 1 received from
the master/follower link. The resulting value is shown by
3.13 M/F or D2D ref1.
M/F ref1 type60.10
0Type and scaling are chosen automatically according to
which reference chain (see settings Torque, Speed,
Frequency) the incoming reference is connected to. If the
reference is not connected to any chain, no scaling is
applied (as with setting Transparent).
Auto
1No scaling is applied.Transparent
2Generic reference with a scaling of 100 = 1 (ie. integer and
two decimals).
General
3
The scaling is defined by parameter 46.3 Torque scaling.
Torque
4
The scaling is defined by parameter 46.1 Speed scaling.
Speed
5
The scaling is defined by parameter 46.2 Frequency
scaling.
Frequency
Torque / uint16Selects the type and scaling of reference 2 received from
the master/follower link. The resulting value is shown by
3.14 M/F or D2D ref2.
For the selections, see parameter 60.10 M/F ref1 type.
M/F ref2 type60.11
Auto / uint16Selects the type/source and scaling of actual value ACT1
transmitted to the master/follower link.
M/F act1 type60.12
Parameters 443
