Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
1 = Process PID setpoint frozen.Setpoint frozenb1
1 = Process PID controller output frozen.Output frozenb2
1 = Sleep mode active.PID sleep modeb3
1 = Sleep boost active.Sleep boostb4
1 = Trim function active.Trim modeb5
1 = Tracking function active.Tracking modeb6
1 = PID output is being limited by par. 40.37.
Output limit highb7
1 = PID output is being limited by par. 40.36.
Output limit lowb8
1 = Deadband active (see par. 40.39)
Deadband activeb9
0 = Parameter set 1 in use. 1 = Parameter set 2 in use.PID setb10
Reservedb11
1 = Internal setpoint active (see par. 40.16…40.24)
Internal setpoint
active
b12
Reservedb13…15
1 = 10000h…FFFFh
Off / uint16Activates/deactivates process PID control. See also
parameter 40.60 Set 1 PID activation source.
Note: Process PID control is only available in external
control; see section Local control vs. external control.
Set 1 PID operation
mode
40.7
0Process PID control inactive.Off
1Process PID control active.On
2Process PID control is active when the drive is running.On when drive
running
AI1 scaled / uint32Selects the first source of process feedback. See the
control chain diagram on page 640.
Set 1 feedback 1
source
40.8
0None.Not selected
1
12.12 AI1 scaled value (page 189).
AI1 scaled
2
12.22 AI2 scaled value (page 191).
AI2 scaled
3
11.39 Freq in 1 scaled.
Freq in scaled
5
1.7 Motor current.
Motor current
6
1.14 Output power.
Power inu out
7
1.10 Motor torque (page 136).
Motor torque
10
40.91 Feedback data storage (page 388).
Feedback data
storage
See Terms and abbreviations (page 132).
Other
Not selected / uint32Selects the second source of process feedback.
For the selections, see parameter 40.8 Set 1 feedback 1
source.
Set 1 feedback 2
source
40.9
376 Parameters
